ZMXM-400 Series
AGENCY SAFETY CERTIFICATIONS
FCC Part 15.247 Module Certified (Portable)
The Matrix modules comply with Part 15 of the Federal Communications Commission rules and regulations. To meet the
FCC Certification requirements, the user must meet these regulations.
? The text on the FCC ID label provided with the module is placed on the outside of the final product.
? The modules may only use the antennas that have been tested and approved with this module.
— The on-board PCB trace antenna
— Nearson S131CL-5-RMM-2450S antenna.
Per section 2.1091, the Matrix module has been certified by the FCC for use with other products without additional
certification. Any modifications to this product may violate the rules of the Federal Communications Commission and make
operation of the product unlawful.
Per sections 15.107 and 15.109, the user ’s end product must be tested to comply with unintentional radiators for
compliance.
Per Section 47 C.F.R. Sec.15.105(b), the Matrix module is certified as a portable device for the FCC radiation exposure
limits set forth for an uncontrolled environment. The antenna used with this module must be installed to provide a
separation distance of at least 8 inches (20cm) from all persons. If the module is to be used in a handheld application, the
user is responsible for passing the additional FCC part 2.1091 rules (SAR) and FCC Guidelines for Human Exposure to
Radio Frequency Electromagnetic Fields, OET Bulletin and Supplement C.
IC Certification — Canada
Matrix modules are IC certified. The labeling requirements for Industry Canada are similar to those of the FCC. A visible
label on the outside of the final product must display the IC labeling. The user is responsible for the end product to comply
with IC ICES-003 (Unintentional radiators).
CE Certification — Europe
Matrix modules are EN 300-328-1 certified in Europe. The user must ensure compliance of the final product with the
European harmonized EMC and safety standards. Annex II of the R&TTE Directive provides the requirements for the
issuance of a Declaration of Conformity. The CE marking must be affixed legibly and indelibly to a visible location on the
user ’s product.
FCC Approved Antennas
? Integrated PCB trace antenna
? Nearson S131CL-5-RMM-2450S – A 2.4GHz Dipole antenna with a 5 inch cable and a right angle MMCX connector.
